TM 5-3895-379-23
VANDAL GUARD REPLACEMENT
THIS WORK PACKAGE COVERS
Removal, Installation
INITIAL SETUP
Equipment Condition
Tools and Special Tools
Engine off (TM 5-3895-379-10)
Tool kit, general mechanic's (Item 36, WP 0220 00)
Drums chocked (TM 5-3895-379-10)
References
TM 5-3895-379-23P, Figure 103
REMOVAL
Remove two shoulder screws (1), washers (2) and vandal guard (3) from instrument box assembly (4).
1
3
2
4
401-731
INSTALLATION
1.
Install vandal guard (3) on instrument box assembly (4) with two washers (2) and shoulder screws (1).
2.
Remove chocks (TM 5-3895-379-10).
END OF WORK PACKAGE
