TM 5-3895-379-23
MUFFLER AND TAILPIPE REPLACEMENT - CONTINUED
0048 00
REMOVAL - CONTINUED
WARNING
Use caution when handling heavy parts. Provide adequate support during procedure. Failure to follow this
warning may cause injury.
NOTE
11
8
10
Muffler weighs 19 lb (8.6 kg).
7
12
3.
Remove nut (7), washer (8), screw (9), washer (8) and
9
clamp (10) from plate assembly (11) and muffler (4).
8
4.
Remove muffler (4) from tube assembly (12).
4
10
401-392
5.
Remove two nuts (13) and clamp (14) from bracket
18
(15).
6.
Remove three nuts (16), tube assembly (17) and gas-
ket (18) from turbocharger assembly (19). Discard
19
gasket.
21
7.
Remove two screws (20), washers (21) and bracket
22
16
(15) from engine (22).
20
17
14
13
15
401-393
0048 00-3
