TM 5-3895-379-23
ENGINE WIRING HARNESS REPLACEMENT - CONTINUED
0109 00
REMOVAL - CONTINUED
24.
Disconnect engine wiring harness clip (70) from starting aid (71).
71
70
401-570
25.
Position boot (72) to expose cable (73) end and remove nut (74), lockwasher (75) and cable (73) from starter (76). Dis-
card lockwasher.
26.
Open cover (77) on starter (76) and remove screw (78), lockwasher (79) and cable (80) from starter (76). Discard lock-
washer.
27.
Note position of engine wiring harness. Carefully remove wiring harness from roller.
78
79
80
75
74
73
76
72
77
401-571
0109 00-9
