FUEL FILTER ASSEMBLY MAINTENANCE - CONTINUED
0040 00
FUEL FILTER ELEMENT ASSEMBLY REMOVAL - CONTINUED
8.
Loosen two nuts (22) and (23) and remove two tubes
7
22
24
26
(24) and (25) and bushings (26) and (27) from fuel fil-
ter assembly (7). Discard bushings.
23
27
25
401-365
9.
Loosen nut (28) and remove tube (29) and sleeve (30)
29
28
36
30
35
33
from connector (31). Discard sleeve.
10.
Loosen connector (32) and remove hose (33) from
tube (34).
11.
Loosen nut (35) and remove tube (34) and damper
(36) from connector (31). Discard damper.
32
34
31
401-366
12.
Remove two nuts (37), two screws (38), clip (39),
40
39
38
hose (40) and fuel filter assembly (7) from bracket
(41).
13.
If damaged, remove two screws (42) and bracket (41)
7
from engine block (43).
37
41
43
42
401-367
